Raymond zeb pulverizer yog dab tsi?
Raymond zeb feem ntau yog siv los ua cov khoom tsis yog-flammable, non-explosive, non-metallic minerals (xws li limestone thiab calcite) nrog Mohs hardness tsawg dua los yog sib npaug li 7 thiab noo noo ntawm <6% rau hauv hmoov zoo.
ib - nres kev daws teeb meem
Adjustable Mesh suav,
siab zoo
Vim li cas cov cuab yeej no tsim nyog yuav?
Kev lag luam muaj zog thov rau cov hmoov ua tiav, ntxiv rau kev muag khoom dav. Koj tau txais lub sijhawm them rov qab luv luv thiab muaj txiaj ntsig ruaj khov.
Adjustable sib tsoo fineness txhais tau hais tias ib lub tshuab ua haujlwm ntau txoj haujlwm. Ib chav tsev tuaj yeem txhawb ntau hom kev siv.
Zog-nqi thiab nqi- zoo. Piv nrog rau qhov sib npaug, kev siv hluav taws xob poob qis dua 30% - cov nqi khiav lag luam poob qis.
Siab automated ntau lawm. Tsawg kev cia siab ntawm kev siv tes ua haujlwm - koj tuaj yeem khiav ntshiv.
Me me hneev taw, tsis tshua muaj teeb meem rau kev teeb tsa ib tsob nroj. Kev nqis peev tsawg kawg nkaus, khiav nrawm rau kev ua haujlwm.
Tsawg suab nrov thiab tsis muaj plua plav ua haujlwm - huv si thiab ib puag ncig zoo. Koj tuaj yeem ua haujlwm ntev, ua haujlwm tsis tu ncua yam tsis muaj kev txhawj xeeb.
Hnav-tiv taus thiab ruaj khov qhov chaw, nrog rau qhov tsis tshua muaj kev ua haujlwm tsawg. Txawm tias khiav 24/7, xyoo hauv thiab tawm xyoo, kev ua tau zoo nyob twj ywm pob zeb.
Tshuab Parameters Table
|
Qauv |
Number of Sib Tsoo Rollers |
Max. Feed Loj (mm) |
Cov khoom tiav Fineness (mesh) |
Peev xwm ib teev (t / h) |
Lub cev muaj zog (kW) |
Lub cev muaj zog (kW) |
Lub zog hluav taws xob (kW) |
hnyav |
Loj(m) |
|
3R1510 |
3 |
10 |
80-325 |
0.3-1.2 |
7.5 |
5.5 |
1.1 |
1.8t |
3.*3*3.8 |
|
3R2615 |
3 |
20 |
80-325 |
0.5-2.7 |
18.5 |
15 |
2.2 |
3.8t |
4*4*4.8 |
|
3R/4R3016 |
3/4 |
20 |
80-325 |
0.8-5 |
30 |
30 |
2.2 |
4.8t |
4*4*4.8 |
|
4R3216 |
4 |
25 |
80-325 |
1.0-8 |
37 |
30 |
5.5 |
10t |
6*6*7 |
|
4R3220 |
4 |
28 |
80-400 |
1-10 |
45 |
37 |
5.5 |
10t |
6*6*7 |
|
5R4121 |
5 |
30 |
80-400 |
5-10 |
75 |
75 |
7.5 |
20t |
7*7*8 |
| nqe (usd) | $4989-$50000 | ||||||||
Saib ntawm lub rooj? Nws tsuas yog hais txog cov neeg raug liam ib txwm muaj- cov qauv uas txhua tus neeg thov ua ntej. Tab sis peb tau txais cov tsiaj nyaum loj thiab me me, leaner units zaum hauv peb cov kab. Xav specs ntawm cov? Tso peb qhov kev nug; uas yog li cas tiag deals pib.
Tam sim no, tsis txhob nug tus nqi tas li. Txhua tus neeg uas tau xa cov khoom sib tsoo paub: koj qhov chaw nyob thiab qhov chaw nres nkoj qhov chaw hloov txhua yam. Kev lis kev cai clearance, hiav txwv freight, cov se hauv zos-nws tag nrho ntxiv sib txawv. Yog li ntawd, rau qhov kev tsocai tiag, tham ncaj qha rau peb cov neeg muag khoom. Lawv yuav tsoo cov lej raws li qhov koj tau tsaws lub tshuab.
Cov khoom siv raw yog dab tsi?
Saib, lub tshuab no muaj nws qhov chaw qab zib. Peb tab tom tham cov khoom tsis yog hlau uas yuav tsis ntes hluav taws lossis tawg. Hardness? Cap nws ntawm Mohs 7. Moisture? Khaws nws qis dua 6%. Hla ob kab, thiab koj yuav foom phem rau hnub koj yuav nws. Cov ntaub ntub dej txhaws cov chutes, thiab txhua yam nyuaj tsuas yog luag ntawm koj cov menyuam.
Dab tsi ua haujlwm? Ntau. Limestone, calcite, marble, thiab dolomite- cov no yog cov mov ci txhua hnub. Txawm tias granite scraps, pebbles, dej pob zeb, yog tias koj tau txais lawv crushed. Nyob rau sab softer: talc (slippery li ntuj raug txim, tab sis nws grinds), barite, fluorite, potash feldspar, albite. Tom qab ntawd quartz yog txoj cai ntawm qhov txwv hardness, yog li saib koj cov khoom hnav. Wollastonite, mica, magnesite, bauxite? Txhua qhov kev ua si, muab rau koj ua ntej ziab yog tias xav tau.
Koj pom Raymond lub tais mills tawm hauv thaj teb txhua lub sijhawm. metallurgy, kev tsim kho, mining, tshuaj lom neeg, kev tsim vaj tsev -lawv tau khwv tau lawv khaws cia hauv txhua qhov qias neeg ntawm kev lag luam hnyav. Tab sis ntawm no yog qhov uas neeg feem coob nco: nws tsis yog hais txog crushing pob zeb. Cov hmoov no mills tso tawm? Qhov ntawd yog koj inorganic muab tub lim. Mus rau txhua txoj kab putty hmoov, ob txheej txheej ya tshauv ua haujlwm -koj yuav pom nws. Xim thiab coatings? Tib zaj dab neeg. Lub zog cog desulfurization? Lawv yuav tsis khiav tsis muaj nws. Plastic fillers, tshuaj txhuam hniav, thiab txawm tias daim ntawv. Yog, ntawv.
Ib yam uas kuv tau kawm: tib lub tshuab uas grinds desulfurizer ntawm 325 mesh tuaj yeem hloov mus rau tshuaj txhuam hniav - qib nplua nyob rau yav tav su. Tsuas yog saib koj cov classifier ceev thiab ua kom cov dej noo qis. Cov txiv neej uas tsis quav ntsej qhov ntawd xaus nrog lumpy filler thiab pissed-tawm cov neeg siv khoom.
Yog li, ua li cas lubRaymond zeb pulverizerua hauj lwm?
Saib, ntawm no yog yuav ua li cas peb muag qhov teeb tsa no: ua tiav pob. Cheebtsam, cais (separator), blower, cyclone, ntxiv rau tag nrho cov motors thiab hluav taws xob tswj. Koj tsis tuaj yeem xaiv ib thooj thiab cia siab tias cov hmoov yuav tawm los. Tag nrho lub tsheb ciav hlau yuav tsum tau khiav ua ke -tsis muaj kev zam, tsis muaj ib nrab ntsuas.
Cov khoom xyaw yog lub cev sib cais. Qhov ntawd tsis yog qhov tsim teeb meem; nws yog rau koj lub siab dawb paug. Thaum lub classifier blades hnav, los yog lub cev muaj zog bearing, koj swap tsuas yog qhov phem. Koj tsis tas yuav teeb lub system tag nrho.
Nta
Ib Daim Ntawv Ua tiav yog Tsis-Tshaj Tawm
Koj puas xav tau hmoov? Tom qab ntawd koj khiav tag nrho damn kab: chav tsev loj, classifier, blower, cyclone collector, thiab lub cev muaj zog. Tsib daim, ib lub plawv dhia.
Vertical Closed-Circuit Circulation
Compact footprint? Koj bet. Qhov kev teeb tsa ntsug tau nyem rau hauv cov khw muag khoom nruj uas qhov chaw hauv pem teb raug nqi tiag tiag. Qhov tsis zoo-siab cua Circuit Court loops rov qab rau nws tus kheej, nrog xoom to thiab xoom plua plav tawm tawm.
Roller-Grinding Mechanism
Ntawm no yog lub physics: centrifugal quab yuam slams lub rollers tiv thaiv lub nplhaib sib tsoo. Scraper hniav khaws cov khoom noj nce mus rau hauv qhov chaw crush. Hnav kuj ceeb heev; ntxeev lub rollers tom qab rau lub hlis, thiab koj tau txais lwm ib nrab xyoo ntawm lub neej.
Adjustable Cua Classification
Tus classifier impeller ceev? Tig ib lub xov tooj. Qhov ntawd yog nws. Koj tuaj yeem sib pauv los ntawm 80-mesh ntxhib mus rau 400-mesh zoo hauv tib qho kev hloov.
Tej yam khoom txwv – hwm lawv
Lub tshuab no noj cov zaub mov uas tsis yog xim hlau ntawm Mohs Tsawg dua lossis sib npaug li 7 thiab noo noo qis dua 6%.
Yam tsawg kawg nkaus - Ua Vajtswv tsaug
Tsuas yog peb yam hnav tawm: rollers, rings, thiab scraper hniav. Qhov ntawd yog nws. Classic tsim, tsis muaj qhov tsis hnov tsw. Ib lub caij nyoog tech tuaj yeem pauv lawv qhov muag tsis pom kev, unbolt, nqa, thiab xaub cov tshiab hauv.
Fully Enclosed thiab Dust-Free
Cua loops nyob rau hauv, los ntawm ib tug built-in rov qab duct. Plua plav tsis pom hnub ci. Kuv tau taug kev cov neeg soj ntsuam los ntawm kev khiav mills nrog lub tsho dawb rau, thiab taug kev tawm tseem huv. Kev ua raws li Environmental? tuav.
Qhov zoo ntawm Kev Yuav Raymond Mills los ntawm Peb Lerford:
Direct los ntawm Chaw Tsim Tshuaj: Tus Nqi Rau Nyiaj Yog Cov Kab hauv qab
Peb tsim nws tus kheej, thiab peb muag nws tus kheej. Cov neeg nruab nrab? Tsis muaj dab tsi. Peb txiav tawm tag nrho cov cim thiab xa cov nyiaj khaws cia ncaj qha rau koj. Tus nqi koj them yog lub Hoobkas - tus nqi ncaj qha. Tsis tas li ntawd, peb cov khoom seem yog cov khoom OEM tiag, thiab lawv cov nqi yog pob tshab tag nrho -koj paub tseeb tias tus nqi tag nrho.
Kev Pabcuam Kev Noj Qab Haus Huv Tag Nrho-Ntau dua li Cov Lus Qhia ntawm Phab Ntsa
Ua ntej-muag: Tsis Muaj Kev Sib Tham
Xav tau kev pab xaiv tus qauv zoo? Peb pib los ntawm kev nug koj cov lus nug tseem ceeb: Dab tsi yog cov khoom siv raw? Nws cov ntsiab lus noo noo yog dab tsi? Puas yog koj lub hom phiaj fineness 200 mesh lossis 325 mesh? Puas yog lub zos qhov siab siab? Yog tias peb tsis qhia meej cov ntsiab lus no ua ntej, muab koj nrog lub tshuab loj loj yuav ua tiav cov hluav taws xob pov tseg. Peb muab kev pabcuam tsim qauv pub dawb-Peb tseem yuav xa ib pab neeg los ua haujlwm ntawm -kev tshuaj xyuas qhov chaw ntawm koj qhov chaw. Qhov no tsis yog ib tug cursory glance; peb nqa daim kab xev ntsuas los txheeb xyuas qhov dav dav ntawm koj lub Hoobkas qhov rooj thiab cov khoom thauj -cov kabmob muaj peev xwm ntawm koj lub hauv paus. Peb tau ua cov haujlwm no ntau pua zaus, yog li peb paub tseeb tias qhov chaw muaj peev xwm nyob qhov twg - txawm tias peb lub qhov muag kaw.
Nruab nrab- muag: Peb Pom Kev Txhim Kho thiab Kev Ua Haujlwm mus txog qhov kawg
Thaum lub tshuab tuaj txog, peb xa peb cov kws tshaj lij rau koj qhov chaw. Peb tsis yog tso tseg phau ntawv qhia thiab taug kev mus. Los ntawm kev txhim kho lub hauv paus thiab zawm thauj tog rau nkoj bolts mus rau kev siv cov sealant ntawm cov pa hauv qhov sib txuas, peb pab neeg muab ob txhais tes- rau, kauj ruam - los ntawm - cov kauj ruam qhia. Peb siv lub tshuab rau kev sim khiav, sau cov hmoov nplej, thiab siv cov sieves los xyuas qhov zoo. Yog tias nws ua tau raws li cov lus qhia tshwj xeeb, koj kos npe tawm ntawm nws; yog tsis yog? Peb cov kws tshaj lij nyob twj ywm kom txog thaum nws ua. Txoj haujlwm tsis suav tias yog ua tiav kom txog thaum koj cov neeg ua haujlwm tuaj yeem kho qhov kev faib tawm nrawm kom ua tiav ob qho kev ua haujlwm siab thiab ruaj khov. Peb ua kev cob qhia tiag tiag- nws tsis yog ib txoj hauv kev xwb. Kuv tau pom deb dhau lawm ntau lub chaw tsim khoom raug kev txom nyem 30% tso tawm tsuas yog vim tias ib qho kev sib tsoo lub kaum sab xis tsis raug kho kom raug-ib qho teeb meem uas lawv tsis tuaj yeem kuaj xyuas lawv tus kheej.
Tom qab-muag: Kev Pabcuam Rau Lub Neej
Tsib xyoos ntawm txoj kev, yog tias koj txiav txim siab tias koj xav hloov qhov zoo ntawm koj cov zis lossis hloov mus rau kev sib tsoo lwm hom ore, tsuas yog hu rau peb. Tus tib neeg heev yuav teb xov tooj thiab muab cov kev daws teeb meem rau koj, dawb kiag li.
|
|
|
|
|
Cov ntsiab lus
Qhov noRaymond zeb pulverizertxais yuav ib qho kev sib koom ua ke tag nrho - teeb tsa nrog ntsug kaw -circuit tsis zoo- siab ncig, siv centrifugal roller sib tsoo thiab pneumatic adjustable classification, haum rau qis -hardness non-hlau cov minerals, featuring ob peb yam yooj yim - qhov chaw, txuag lub zog thiab kev sib khi, - qhov chaw plua plav-dawb, thiab ua haujlwm zoo ib puag ncig.
