Raymond Mill Tshuab
Saib, ntawm no yog dab tsi Raymond zeb tiag tiag yog: lub kaw lus kaw tau tsim tshwj xeeb rau cov khoom siv tsis yog hlau. Tsis yog "universal grinder" - tailored.
Nws txoj hauj lwm? Yooj yim. Koj pub nws pob zeb, nws muab hmoov rau koj. Tab sis tus ntes yog nyob rau hauv qhov zoo. Cov hmoov tuaj tawm tsis sib xws thiab ruaj khov. Tsis muaj viav vias qus hauv qhov me me raws li koj tau txais nrog cov khoom pheej yig dua - koj paub, qhov kev ntxhov siab sib xyaw ntawm cov nplua thiab ntxhib pob.
Txoj cai ntawm tus ntiv tes xoo: yog tias cov pob zeb tsis tawg los yog tawg, hardness tsawg dua lossis sib npaug li 9, noo noo qis dua 6% - koj zoo mus. Xav tias hauv av calcium carbonate, talc, gypsum, potash feldspar. Cov no yog cov mov ci txhua hnub.
Thiab fineness? Koj tuaj yeem hu nws los ntawm 80 mesh mus txog 600 mesh. Yuav ua li cas? Ntawm lub tshuab tiag tiag, koj tweak lub classifier rotor ceev thiab kho cov kiv cua airflow. Tau txais ob txoj cai, thiab qhov txiav taw tes nyob twj ywm ntse - tsis muaj kev kwv yees.
Siab Zoo
Khoom siv Advanced
Tsim tshwj xeeb
Kev siv dav dav
siab zoo
Nruab nrog kev sib xyaw plua plav tshem tawm, nws txo cov plua plav tawm thiab ua raws li cov qauv ib puag ncig.
Khoom siv Advanced
Cov cuab yeej no nta adjustable fineness (80-600 mesh).
Tsim tshwj xeeb
Compact Structure, Me Me Hneev taw, Yooj yim installation thiab commissioning
Kev siv dav dav
Haum rau nruab nrab -rau- tsis tshua muaj hardness tsis yog- cov khoom siv hlau xws li limestone, calcite, gypsum, thiab talc (nrog Mohs hardness tsawg dua 9).
Parameter Table Zaub
| Qauv | Number of Sib Tsoo Rollers | Max. Feed Loj (mm) | Cov khoom tiav Fineness (mesh) | Peev xwm ib teev (t / h) | Lub cev muaj zog (kW) | Lub cev muaj zog (kW) | Lub zog hluav taws xob (kW) | Qhov hnyav | Loj (m) |
|---|---|---|---|---|---|---|---|---|---|
| 3R1510 | 3 | 10 | 80–325 | 0.3–1.2 | 7.5 | 5.5 | 1.1 | 1.8t | 3.8×3×3.8 |
| 3R2615 | 3 | 20 | 80–325 | 0.5–2.7 | 18.5 | 15 | 2.2 | 3.8t | 4.8×4×4.8 |
| 3R/4R3016 | 3/4 | 20 | 80–325 | 0.8–5 | 30 | 30 | 2.2 | 4.8t | 4.8×4×4.8 |
| 4R3216 | 4 | 25 | 80–325 | 1.0–8 | 37 | 30 | 5.5 | 10t | 7×6×6 |
| 4R3220 | 4 | 28 | 80–400 | 1–10 | 45 | 37 | 5.5 | 10t | 7×6×6 |
Vim li cas cov cuab yeej no tsim nyog yuav?
1. Kev nqis peev tsawg, kev them rov qab sai - ntawm no yog qhov txhais tau tiag tiag.
Koj tsis yog yuav ib lub zeb xwb. Koj tau txais cov hmoov ua tiav hauv ib lub chassis. Tsis muaj cais feeder, tsis muaj classifier ntxiv, tsis muaj siab conveying system rau piece ua ke. Qhov ntawd txo koj cov haujlwm hauv pej xeem thiab cov cuab yeej pabcuam. Rau ib qho me me - rau - nruab nrab cov nroj tsuag, qhov no txiav cov nyiaj tau los ntawm thawj zaug kwv yees li 40% piv rau kev tsim cov kab ib txwm muaj los ntawm kos. Tsawg zog ntawm koj cov peev nyiaj ua haujlwm - thiab koj pib muag hmoov lub hlis dhau los.
2. Lub zog tshaib plab? Tsis yog tus no.
Peb tab tom tham txog 30% + hluav taws xob tsawg dua lub pob zeb ntawm cov khoom sib xws. Khiav nws ob zaug ib hnub, thiab cov nqi hluav taws xob txhua hli sib txawv them rau ib tus neeg ua haujlwm cov nyiaj hli. Tom qab ib xyoos? Qhov ntawd yog cov paj tiag tiag rov qab rau hauv koj lub hnab ris. Kuv tau pom cov nroj tsuag retrofit los ntawm pob zeb rau Raymond - lawv cov nyiaj them rov qab ntawm qhov hloov ib leeg tuaj hauv 12 lub hlis xwb los ntawm kev txuag hluav taws xob.
3. Nyuaj qhov twg suav, yooj yim kom khiav.
Qhov tsis ua hauj lwm tus nqi yog tsawg vim hais tias tus tsim yog stubbornly yooj yim. Tsuas yog ob peb qhov hnav - feem ntau yog lub nplhaib sib tsoo thiab cov chais. Hloov lawv thaum lub sij hawm npaj kaw lub lis piam, tsis yog thaum muaj xwm txheej ceev thaum 2 teev sawv ntxov. Kev tu txhua hnub? Lub sij hawm greasing thiab xyuas cov hniav ntsuas - yog nws. Downtime nyob qis dua 5% yog tias koj nyob ib nrab ntawm kev saib xyuas.
4. Haum rau qhov chaw nruj, bolted ceev ceev.
Hneev taw yog me me - kwv yees li 25 m² rau tag nrho chav tsev, suav nrog cov khoom siv plua plav. Thiab installation? Ncuav ib qho yooj yim qhob ncoo, thauj tog rau nkoj, thiab txuas lub zog thiab cua kav. Tsis muaj ntau zaj dab neeg steel qauv zoo li lub pob zeb xav tau. Koj tuaj yeem mus los ntawm kev xa mus rau thawj pawg ntawm cov hmoov hauv qab ib lub lim tiam.
5. Teeb nws thiab tsis nco qab nws - yuav luag.
Automation tswj qhov pib-nres ib ntus, kev sib txuam nrawm nrawm, thiab kev hloov pauv hloov pauv. Ib tus neeg teb xov tooj tuaj yeem zov peb chav nyob ib txhij. Kev ua haujlwm ntawm tes yog qhov pib tsuas yog thauj lub hopper thiab xyuas cov khoom ntim khoom. Rau cov nroj tsuag tawm tsam nrhiav cov kws txawj zeb tes, qhov ntawd yog kev ua si - hloov pauv.
Cov ntaub ntawv dab tsi yog ua los ntawm Raymond Mill Tshuab?
Non-metallic mineral sib sib zog nqus ua - uas yog koj hnyav calcium, lub teeb calcium, talc, gypsum, kaolin. Lawv muaj dab tsi sib xws? Lawv tag nrho mus ua hauj lwm fillers. Plastics, coatings, roj hmab, ntawv, ceramics - koj npe nws. Tab sis ntawm no yog cov lus qhia: lub teeb calcium clogs yooj yim dua li cov calcium hauv av. Yog li yog tias koj tab tom khiav Raymond zeb rau nws, saib koj cov dej noo. Khaws cov pob txha qhuav.
Cov khoom siv hauv tsev thiab cov cement - limestone hmoov rau desulfurization ntawm cov nroj tsuag fais fab, gypsum rau phab ntsa, putty hmoov, thiab cement raw mov. Cov khoom desulfurization? 250 mesh lossis 325 mesh, tsis muaj dab tsi zoo nkauj. Tab sis cement nroj tsuag yog picky txog particle loj nkhaus. Kev nplua ntau dhau thiab koj lub sijhawm teem caij drifts.
Tshuaj thiab metallurgy - phosphate pob zeb, manganese ore, pulverized thee, metallurgical auxiliaries, refractories, activated carbon. Phosphate yog abrasive. Noj los ntawm kev sib tsoo rings sai dua li koj xav. Npaj lub nplhaib hloov tom qab 600-800 teev yog tias koj khiav nws txhua hnub.
Kev tiv thaiv ib puag ncig / khoom siv pov tseg - slag, steel slag, granulated blast furnace slag (GBFS). Sib tov nws mus rau ultrafine hmoov, thiab nws dhau los ua ib qho kev ua haujlwm siab ua vaj tse. Tus ntes? Steel slag yog tawv - cov ntsiab lus hlau siab tua mills yog tias koj tsis hu rau tus nqi pub. GBFS yog tus phooj ywg zoo dua, tab sis qhuav nws ua ntej. Cov dej noo siab tshaj 2% thiab koj cov khoom sib cais chokes.
Cov khoom tiav ntawm Raymond zeb muaj cov hmoov ultrafine xws li 80 mus rau 325 mesh (nrog qee qhov ntau txog 400 txog 600 mesh). Cov yam ntxwv los ntawm kev ua kom zoo nkauj zoo nkauj thiab kev soj ntsuam siab dhau (txog 99%), cov khoom siv feem ntau nthuav tawm raws li cov hmoov zoo, muag heev -dawb los yog lub teeb grey hauv cov xim- tsis muaj kev pom pom zoo.
Hom Daim Ntawv Thov Kev Lag Luam - qhov twg lub zeb no tau txais txiaj ntsig nws khaws cia.
Cov khoom siv hauv tsev:Cement, putty hmoov, gypsum board.
Cement nroj tsuag xav kom lawv cov nqaij nyoos zoo tab sis tsis zoo heev - 80 mus rau 120 mesh feem ntau ua nws. Putty hmoov? Qhov ntawd yog 325 mesh kev ua si. Thiab gypsum board? Koj zom nws mus rau 150-200 mesh, tab sis khaws qhov kub thiab txias. Kub dhau heev thiab koj poob cov dej siv lead ua - ces koj lub rooj tsavxwm yuav tsis teeb.
Tshuaj:Roj hmab, yas, txheej, ntawv sau.
Ntawm no yog qhov qias neeg tsis pub leejtwg paub: daim ntawv muab tub lim xav tau siab dawb, tsis yog qhov zoo xwb. Yog li yog tias koj cov calcium carbonate muaj txawm tias ib qho lus pom ntawm grey, tsis txhob thab kev sib tw. Roj hmab thiab yas saib xyuas ntau dua txog kev txiav sab saum toj - txhua yam saum toj no 20 microns ua rau qhov chaw tiav.
Kev tiv thaiv ib puag ncig:Desulfurization limestone hmoov.
Cov nroj tsuag muaj zog. Yuav tsum yog 250 mesh lossis 325 mesh, nrog rau kev xa tawm nruj. Pass tus nqi ntawm 325 mesh? 90% yam tsawg kawg nkaus, lossis lawv yuav tsis lees txais tag nrho cov tsheb thauj khoom. Thiab noo noo nyob rau hauv 0.5% - nplaum limestone clogs qhov txhaj tshuaj zoo li tsis muaj dab tsi ntxiv.
Metallurgy, iav, thiab ceramics:Cov khoom nyoos.
Metallurgical auxiliaries - xav quartz, fluorite, feldspar. Cov iav batch xav tau cov ntsiab lus hlau hauv qab 0.1%, lossis koj cov iav tiav hloov ntsuab. Ceramics? Lawv tshuaj xyuas txhua yam coarser dua 200 mesh. Nco nws, thiab koj qhov chaw glazed tsim pinholes.
Pub thiab fertilizer additives:Calcium hmoov.
Qaib xav tau grit - uas yog ntxhib 30-50 mesh. Tab sis rau premixes? 60-100 mesh limestone hmoov, nruj me ntsis. Thiab tsis txhob, tsis txhob cia nws damp. Caked calcium nyob rau hauv pub txhais tau tias thaiv augers thiab npau taws zeb tswj.
Dab tsi yog cov yam ntxwv?
Siab Zoo
Qhov no tsis yog tsuas yog ib lub zeb - nws yog ib tug standalone milling system. Pub nws raw khoom ntawm ib kawg, sau tiav cov hmoov ntawm lwm yam. Tsis muaj cov khoom siv ntxiv, tsis muaj cov khoom sib cais los ua ke. Tus hneev taw? Tight. Tus qauv? Khoom - welded steel phaj, tsis muaj flex nyob rau hauv load. Koj tuaj yeem nres nws rau ntawm kaum ntawm cov nroj tsuag uas twb muaj lawm thiab tseem muaj chaw taug kev ncig.
Customized Tsim
Txawm fineness? Qhov ntawd yog lub ntsiab lus. Tab sis ntawm no yog tus kicker tiag tiag: qhov kev ntsuam xyuas dhau tus nqi hits 99%. Sim qhov ntawd ntawm lub pob zeb - koj yuav muaj hmoo pom 85% ntawm tib lub mesh. 99% txhais li cas rau hauv pem teb? Tsawg dua rework, tsawg dua cov khoom tsis lees paub, thiab koj cov neeg siv khoom tsis txaus siab txog cov khoom loj loj clogging lawv cov ntxaij lim dej.
Kev ua tau zoo
Saib sab hauv tsav tsheb ciav hlau. Kaw lub gearbox ntxiv rau lub pulleys - tsis yog ib qho qhib iav teeb uas haus cov plua plav thiab nplawm cov roj txhua qhov ua haujlwm. Lub foob khaws cov hmoov zoo tawm ntawm cov kabmob. Qhov tshwm sim? Kev sib kis tau yooj yim, tsis muaj kev xav txog kev puas tsuaj. Koj mam li hloov cov roj ib zaug ib lub caij thiab tsis nco qab txog nws.
Taw qhia txog Cov Khoom Siv Hluav Taws Xob thiab Cov Kab Ntau Lawm
I. Tag Nrho Cov Txheej Txheem Flow – Los ntawm Pob Zeb Rau Lub Hnab.
Raw Material Crushing → rhuav cov pob loj kom qis dua 30 hli. Hla cov kauj ruam no, thiab koj lub zeb chokes.
Lifting & Conveying → thoob of elevator lossis siv? Txoj siv tawv yog softer, tab sis siv ntau qhov chaw hauv pem teb. Koj hu.
Quantitative Feeding → ib tug ntsia hlau feeder los yog vibratory feeder nrog ib tug sib txawv tsav. Teem tus nqi yog, los yog lub zeb txawm tshaib plab los yog dej nyab.
Main Mill Sib Tsoo - qhov no yog qhov uas cov chais raug tshem tawm ua haujlwm tiag tiag. Crush, shear, rov ua dua.
Classification & Separation → tus classifier spin ntawm lub teeb RPM. qeeb dhau lawm? Coarse hais nkag mus. nrawm dhau lawm? Tso zis poob.
Cov khoom tiav tiav → cyclone ntxiv lub hnab lim. Cyclone ntes cov khoom hnyav; lub hnab lim grabs cov nplua uas yuav txwv tsis pub ntab mus.
Kev tshem tawm plua plav & Purification → kab kawg ntawm kev tiv thaiv. Khaws koj pawg kom huv si, lossis tus kws tshuaj xyuas ib puag ncig pib nug cov lus nug.
Tag nrho cov tshuab teev saum toj no tam sim no muaj muag los ntawm peb lub tuam txhab. Tej zaum lawv yuav yuav ib tus zuj zus los yog ua tiav cov kab ntau lawm. Peb zoo siab tos txais koj tuaj yeem tiv tauj peb rau kev nug.
Qhov zoo ntawm kev xaiv Lerford yog dab tsi?
One-Stop Service ntawm Raymond Mill Tshuab - hom uas ua rau koj mob taub hau.
Koj xav customization? Peb mam li spec nws rau koj cov khoom noj khoom haus thiab phiaj mesh. Tsis muaj lub khob noom cookie-cutter.
Kev npaj pub dawb ntawm qhov chaw thiab kab tsim - peb yuav xa daim duab kos ua ntej koj them ib xees.
Tag nrho lub tshuab warranty + lub sij hawm ntev spare qhov chaw muab khoom - cov khoom qub, tsis knockoffs uas hnav tawm hauv ib nrab lub sijhawm. Thiab thaum twg koj hu? Teb kev txhawb nqa. Tsis yog daim pib uas ploj mus rau peb hnub.
Kev them nyiaj yooj yim, kev txwv tsis pub nkag - ntawm no yog qhov ua tau zoo li cas: them nyiaj tso nyiaj (feem ntau 30% txog 50%) pib tsim khoom. Qhov nyiaj tshuav? Vim thaum lub tshuab thauj khoom mus rau lub tsheb thauj khoom, npaj rau nkoj. Qhov ntawd ua rau koj cov nyiaj ntws tau yooj yim - koj tsis tau los ntshav rau rau lub hlis ua ntej pom ib qho flange.
Seamless kev koom ua ke - elevator, ntsia hlau feeders, plua plav collectors, cia hoppers - peb muab tag nrho lub tsheb ciav hlau. Ib PO, ib tus neeg tiv tauj, ib qho pib. Tsis muaj chasing tsib lwm tus neeg muag khoom vim lub thoob of elevator tsis phim lub zeb inlet.
Cov kab hauv qab: Nws yog cov hmoov kab ua tiav, tsis yog ib lub zeb nrog ob peb add-ons.
 |
 |
 |
 |
Peb Raymond zeb twb tau ua haujlwm ntau lub tebchaws, suav nrog Bangladesh thiab Ecuador.
Cim npe nrov: Tuam Tshoj raymond zeb tshuab lwm tus neeg, Hoobkas
