Daim ntawv thov ntawm mis nyuj packing tshuab:
Lub tshuab ntim mis no yog tsim rau qhov hnyav hlais, yob, lossis cov khoom zoo li niaj zaus thiab cov hmoov ntxhua me me. xws li qab zib, ntsev, noob, nplej, noob hnav, glutamate, mis hmoov, kas fes hmoov thiab seasoning hmoov, me me granule, chips, thiab lwm yam (mov packing tshuab).
Pob khoom ntawm mis nyuj packing tshuab:BOPP / CPP / VMCPP, BOPP / PE, PET / VMPET, PE, PET / PE, thiab lwm yam.
Ntau hom hnab ntim muaj, xws li hnab, rov qab-sealing hnab, txuas lub hnab, thiab lwm yam (lub hnab ntim mis nyuj tshuab).
Cov ntaub ntawv qhia txog kev siv lub tshuab mis tsis siv neeg packing:
Packing ceev | 5-80 hnab/min | |||
Hnab loj | (Dav) 60-200mm (Length) 50-300mm | |||
Lub hnab ua hom | Lub hnab ntim hauv ncoo, lub hnab sawv ntsug, xuas nrig ntaus, thiab txuas | |||
Ntau qhov ntsuas | 150-1300ml | |||
Qhov siab tshaj plaws ntawm packing zaj duab xis | 420 hli | |||
Kev siv cua | 2 00L/min 0.7 × 105Pa | |||
Main zog / voltage | 2.2KW / 220V 50-60Hz | |||
Dimension | 1400 × 970 × 1600 hli | |||
Tshuab loj | 1350 * 1150 * 1700 hli | |||
Qhov hnyav ntawm switchboard | 400 kg | |||
Modal | 320 | 420 | 520 | 720 |
Kev ntsuas ntau | 150-800ml | 150-1500ml | 150-2000ml | 150-4000ml |
Ntim ceev | 5-70bags/min | 5-60bags/min | 10-60bags/min | 10-60bags/min |
Hnab dav | 50-150 hli | 60-200ml | 80-250 hli | 100-350 hli |
Hnab ntev | 80-240 hli | 80-300 hli | 80-350 hli | 100-450 hli |
Zaj duab xis yob dav | Max.320 hli | Max. 420 hli | Max.520 hli | Max 720 hli |
Zaj duab xis thickness | 0 03-0.09mm | |||
Cov khoom siv zaj duab xis | OPP / CPP PET / PE PET-AL / PE lamination zaj duab xis, aluminium zaj duab xis | |||
Tshuab loj (LxWxH) | 1185 * 935 * 1245 hli | 1217 * 1015 * 1343 hli | 1488 * 1080 * 1490 hli | 1716 * 1260 * 1820mm |
Tshuab hnyav | 350kg ua | 450kg ua | 5 50kg | 700kg ib |
Product details of mis nyuj packing machine:
Qhov kev ua tau zoo thiab cov yam ntxwv ntawm lub tshuab ntim mis mis:
1. PLC computer tswj system.PLC los ntawm Nyiv lossis Lub Tebchaws Yelemees
2. Loj kov Los ntawm Tai wan. Yooj yim rau kev khiav lag luam thiab tswj lub tshuab
3. High precision positioning nrog servo zaj duab xis thauj system.Servo lub cev muaj zog los ntawm lub teb chaws Yelemees Siemens kom ruaj khov.
4. Ceeb toom kev tiv thaiv muaj nuj nqi.
5. Lub tshuab ntim mis tsis siv neeg no yuav ua tiav tag nrho cov txheej txheem ntim khoom los ntawm kev ntsuas, pub mis, txhaws, luam ntawv, lub hnab tiav.
6. Txoj kev ua lub hnab ntim khoom: lub tshuab ntim mis tuaj yeem ua cov hnab ntim hauv ncoo thiab cov hnab ntim khoom raws li tus neeg yuav tsum tau ua. Punching lub hnab & txuas 5-12 hnab thiab lwm yam.
Yuav siv lub tshuab ntim mis li cas?
Khoom nta ntawm lub tshuab mis tsis siv neeg packing:
√ Ntim Ntau: 150 grams - 4000 grams;
√ PLC tswj qhov system, ruaj khov thiab txhim khu kev qha;
√ High precision digital hnyav sensors;
√ 5.7 nti muaj yeeb yuj kov npo;
√ Cov khoom siv sib cuag (kho lub hopper, hopper, vibration phaj, hnyav hopper, thiab lwm yam) yog kom paub ceev disassembly;
√ Yooj yim los ntxuav thiab tu
Qhov zoo ntawm cov mis ntim tshuab:
1. Lub tshuab ntim mis tau txais kev ua haujlwm siab servo zaj duab xis thauj khoom, PLC Program Control, tsim touchable Human-machine Interface ntawm Advanced Automatic Positioning, Photoelectric Tracking, Digital Temperature Control, thiab lwm yam.
2. Kev ua haujlwm ntawm cov mis ntim tshuab yog yooj yim dua, zoo meej. Nws yog thawj qhov kev xaiv ntawm kev lag luam ntim khoom noj los txhim kho kev tsim khoom,
txo kev siv zog ua haujlwm, thiab txhim kho qib ntawm cov khoom ntim khoom.
3. Transverse thiab longitudinal sealing Temperature Control ntawm nws tus kheej, haum rau PE / polyethylene, PE / aluminium plating, tsiaj / PE, pp, thiab lwm yam khoom siv thaum tshav kub kub sealing, thiab lwm yam.
4. Nws ua tiav tag nrho cov txheej txheem ntawm kev sau, ntsuas, ntim khoom, hnub luam ntawv, them nyiaj (exhausting), thiab cov khoom tso tawm tau txais.
5. High precision, high efficiency tsis crashing cov ntaub ntawv.
6. Ntim style diversified, rov qab sealing, gusset hnab, nruam hnab, xuas nrig ntaus, thiab lwm yam.
7. Qhov chaw ua haujlwm nyob ntsiag to, tsis muaj suab nrov, txuag lub zog.
8. Cov cuab yeej ua tiav yog kev lag luam.
